Cisco ASR 1001-X User Manual

Installing AC Power Supplies in the Cisco ASR 1001-X Router
Do not install the power supplies with the chassis cover off.Note
Follow these steps to install AC power supplies to the Cisco ASR 1001-X Router.
SUMMARY STEPS
1.
At the rear of the chassis, ensure that the power switch on the chassis is in the Standby position.
2.
Insert the power supply module into the appropriate slot(s), making sure that the retention latch is firmly
placed. You can verify that the power supply module is firmly latched by gently pulling the power supply
handle.
3.
Insert the power supply cables firmly into the power supplies.
4.
Ensure that the AC power cords are positioned, as shown in the below figure.
5.
If you have changed the Standby switch to the standby position in step 1, turn the Standby switch to the
On position.
DETAILED STEPS
Step 1
At the rear of the chassis, ensure that the power switch on the chassis is in the Standby position.
The below figure shows the Cisco ASR 1001-X Router AC power supply Standby switch.
Cisco ASR 1001-X Router Hardware Installation Guide
94
Removing and Replacing FRUs from the Cisco ASR 1001-X Router
Installing AC Power Supplies in the Cisco ASR 1001-X Router

Cisco ASR 1001-X Specifications

General

Product color	Gray
Rack capacity	1U
Rack mounting	Yes
Networking standards	-
Ethernet LAN (RJ-45) ports	6
Installed SFP modules quantity	2
Flash memory	1024 MB
Internal memory	8192 MB
Processor cores	4
AC input voltage	85 - 264 V
Power source type	AC
Power consumption (typical)	250 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Security algorithms	AES

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	10590 g
