Cisco ASR 1001-X User Manual

Behavior in the
Power-Up State
ColorLEDLED LabelNo.
All the power
supplies are within
operational limits.
GreenPowerPWR1
Major alarm
indicator.
RedMAJORMAJ2
Critical alarm
indicator. Will be
off when the router
is initially powered
up and all the
configured
components are
available.
RedCRITICALCRIT3
Minor alarm
indicator
AmberMINORMIN4
Cisco IOS has
successfully booted.
GreenSTATUSSTAT5
The system is at
ROMMON.
Yellow
System failure. Will
be off when the
router is powered
up.
Red
Indicates that the
mini eUSB
connector is used as
the console.
GreenUSB Console
Enable
EN6
Indicates that the
RJ-45 connector is
being used as the
console.
Off
Cisco ASR 1001-X Router Hardware Installation Guide
4
Cisco ASR 1001-X Router Overview
Cisco ASR 1001-X Router LEDs

Cisco ASR 1001-X Specifications

General

Product color	Gray
Rack capacity	1U
Rack mounting	Yes
Networking standards	-
Ethernet LAN (RJ-45) ports	6
Installed SFP modules quantity	2
Flash memory	1024 MB
Internal memory	8192 MB
Processor cores	4
AC input voltage	85 - 264 V
Power source type	AC
Power consumption (typical)	250 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Security algorithms	AES

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	10590 g
