Cisco ASR 5500 Installation Guide

RequirementCard SequenceSlot
Front of Chassis
Required for all systemsSSC-211
Required for all systemsSSC-112
AvailableFSC-613
Required for all systemsFSC-414
Required for all systemsFSC-215
Required for all systemsFSC-316
Required for all systemsFSC-117
AvailableFSC-518
Reserved19
Reserved20
General Installation Sequence
Circuit cards and baffles are installed in the ASR 5500 chassis as follows:
•
Front circuit cards and baffles are installed from Right to Left. Start at slot 20 and continue to slot 11.
Slots 19 and 20 always require baffles.
•
Rear circuit cards and baffles are installed from Left to Right. Start at slot 1 and continue to slot 10.
Complete the installation of each card (includes securing the card in the chassis using a Phillips #2 screwdriver
before proceeding to the next card.
You can install all circuit cards and then install baffles to cover empty chassis slots. It does not matter whether
you install all front cards or all rear cards first.
ASR 5500 Installation Guide
51
Card Installation
General Installation Sequence
