Cisco ASR 5500 Installation Guide

To connect a terminal server to the Console port, do the following:
Step 1
Plug one end of an RJ45 cable to the port labeled Console on the MIO or UMIO.
Step 2
Plug the other end of the RJ45 cable into a port on the terminal server.
Step 3
Configure the communications protocol on the terminal server port to support the following:
•
Baud Rate = 115200 bps
•
Data Bits = 8
•
Parity = None
•
Stop Bits = 1
•
Flow Control = None
For additional information on connecting the Console port to Cisco servers equipped with asynchronous
interface modules, refer to the Console Port to Cisco Server Cabling appendix.
Important
Ethernet Management STP Ports
MIOs/UMIOs support two autosensing RJ45 10/100/1000Base-T (IEEE 802.3ab) Ethernet, shielded twisted-pair
(STP) copper interfaces (logical Ports 1 and 2) for out-of-band system management access to the CLI.
To comply with GR-1089 intra-building, lightning-immunity requirements and FCC Radiated Emissions
Criteria, you must use STP cable and ensure that it is properly terminated at both ends.
Important
The 1000Base-T management ports are suitable for connection to intra-building or unexposed wiring or
cabling only. These intra-building ports MUST NOT be metallically connected to interfaces that connect
to the outside plant (OSP) or its wiring. These interfaces are designed for use as intra-building interfaces
only (Type 2 or Type 4 ports as described in GR-1089-CORE, Issue 5) and require isolation from the
exposed OSP cabling. The addition of Primary Protectors is not sufficient protection in order to connect
these interfaces metallically to OSP wiring.
Caution
The ports support MDI and MDI-X connectors. Ethernet ports normally use MDI connectors and Ethernet
ports on a hub normally use MDI-X connectors.
An Ethernet straight-through cable is used to connect an MDI to an MDI-X port. A cross-over cable is used
to connect an MDI to an MDI port, or an MDI-X to an MDI-X port.
ASR 5500 Installation Guide
66
MIO Port Cabling
Ethernet Management STP Ports
