Cisco Catalyst 2960-X User Manual

DescriptionAttributeSub-Type NumberVendor-Specific
Company Code
Number
Indicates the amount of
time in seconds the modem
sent fax data (x) and the
amount of time in seconds
of the total fax session (y),
which includes both
fax-mail and PSTN time,
in the form x/y. For
example, 10/15 means that
the transfer time took 10
seconds, and the total fax
session took 15 seconds.
Fax-Modem-Time7926
Indicates the modem speed
at which this fax-mail was
initially transmitted or
received. Possible values
are 1200, 4800, 9600, and
14400.
Fax-Connect-Speed8926
Indicates the number of
recipients for this fax
transmission. Until e-mail
servers support Session
mode, the number should
be 1.
Fax-Recipient-Count9926
Indicates that the fax
session was aborted or
successful. True means
that the session was
aborted; false means that
the session was successful.
Fax-Process-Abort-Flag10926
Indicates the address to
which DSNs will be sent.
Fax-Dsn-Address11926
Indicates whether or not
DSN has been enabled.
True indicates that DSN
has been enabled; false
means that DSN has not
been enabled.
Fax-Dsn-Flag12926
Indicates the address to
which MDNs will be sent.
Fax-Mdn-Address13926
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
76 OL-29048-01
Configuring RADIUS
Vendor-Specific RADIUS Attributes

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
