PurposeCommand or Action
•
(Optional) For burst intervalseconds, specify the consecutive
interval in seconds, over which the interface is monitored for a
high rate of ARP packets. The range is 1 to 15.
•
For rate none, specify no upper limit for the rate of incoming
ARP packets that can be processed.
Returns to global configuration mode.exit
Step 5
(Optional) Enables error recovery from the dynamic ARP inspection
error-disabled state, and configure the dynamic ARP inspection recover
mechanism variables.
Use the following commands:
Step 6
•
errdisable detect cause arp-inspection
•
errdisable recovery cause
arp-inspection
By default, recovery is disabled, and the recovery interval is 300
seconds.
•
errdisable recovery interval interval
For interval interval, specify the time in seconds to recover from the
error-disabled state. The range is 30 to 86400.
Returns to privileged EXEC mode.exit
Step 7
Verifies your settings.Use the following show commands:
Step 8
•
show ip arp inspection interfaces
•
show errdisable recovery
Verifies your entries.show running-config
Example:
Switch# show running-config
Step 9
(Optional) Saves your entries in the configuration file.copy running-config startup-config
Example:
Switch# copy running-config
Step 10
startup-config
Performing Dynamic ARP Inspection Validation Checks
Dynamic ARP inspection intercepts, logs, and discards ARP packets with invalid IP-to-MAC address bindings.
You can configure the switch to perform additional checks on the destination MAC address, the sender and
target IP addresses, and the source MAC address.
Follow these steps to perform specific checks on incoming ARP packets. This procedure is optional.
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
OL-29048-01 257
Configuring Dynamic ARP Inspection
Performing Dynamic ARP Inspection Validation Checks

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
