SUMMARY STEPS
1.
enable
2.
configure terminal
3.
ip arp inspection validate {[src-mac] [dst-mac] [ip]}
4.
exit
5.
show ip arp inspection vlan vlan-range
6.
show running-config
7.
copy running-config startup-config
DETAILED STEPS
PurposeCommand or Action
Enables privileged EXEC mode. Enter your password if prompted.enable
Step 1
Example:
Switch> enable
Enters the global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 2
Performs a specific check on incoming ARP packets. By default, no checks are
performed.
ip arp inspection validate
{[src-mac] [dst-mac] [ip]}
Step 3
The keywords have these meanings:
•
For src-mac, check the source MAC address in the Ethernet header against
the sender MAC address in the ARP body. This check is performed on
both ARP requests and responses. When enabled, packets with different
MAC addresses are classified as invalid and are dropped.
•
For dst-mac, check the destination MAC address in the Ethernet header
against the target MAC address in ARP body. This check is performed for
ARP responses. When enabled, packets with different MAC addresses are
classified as invalid and are dropped.
•
For ip, check the ARP body for invalid and unexpected IP addresses.
Addresses include 0.0.0.0, 255.255.255.255, and all IP multicast addresses.
Sender IP addresses are checked in all ARP requests and responses, and
target IP addresses are checked only in ARP responses.
You must specify at least one of the keywords. Each command overrides the
configuration of the previous command; that is, if a command enables src and
dst mac validations, and a second command enables IP validation only, the src
and dst mac validations are disabled as a result of the second command.
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
258 OL-29048-01
Configuring Dynamic ARP Inspection
Performing Dynamic ARP Inspection Validation Checks

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
