PurposeCommand or Action
Enables the 802.1x readiness check on the switch.
dot1x test eapol-capable [interface interface-id]
Step 3
Example:
Switch# dot1x test eapol-capable interface
gigabitethernet1/0/13
(Optional) For interface-id specify the port on which to check
for IEEE 802.1x readiness.
If you omit the optional interface keyword, all
interfaces on the switch are tested.
Note
DOT1X_PORT_EAPOL_CAPABLE:DOT1X: MAC
00-01-02-4b-f1-a3 on gigabitethernet1/0/13 is
EAPOL
capable
(Optional) Configures the timeout used to wait for EAPOL
response. The range is from 1 to 65535 seconds. The default
is 10 seconds.
dot1x test timeout timeout
Step 4
Returns to privileged EXEC mode.end
Example:
Switch(config)# end
Step 5
Verifies your entries.show running-config
Example:
Switch# show running-config
Step 6
(Optional) Saves your entries in the configuration file.copy running-config startup-config
Example:
Switch# copy running-config startup-config
Step 7
Related Topics
802.1x Readiness Check, on page 277
Configuring Voice Aware 802.1x Security
To use voice aware IEEE 802.1x authentication, the switch must be running the LAN base image.Note
You use the voice aware 802.1x security feature on the switch to disable only the VLAN on which a security
violation occurs, whether it is a data or voice VLAN. You can use this feature in IP phone deployments where
a PC is connected to the IP phone. A security violation found on the data VLAN results in the shutdown of
only the data VLAN. The traffic on the voice VLAN flows through the switch without interruption.
Follow these guidelines to configure voice aware 802.1x voice security on the switch:
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
302 OL-29048-01
Configuring IEEE 802.1x Port-Based Authentication
Configuring Voice Aware 802.1x Security

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
