PurposeCommand or Action
Enters interface configuration mode, and specify the
port to be configured.
interface interface-id
Example:
Switch(config)# interface gigabitethernet1/0/2
Step 2
Resets the 802.1x parameters to the default values.dot1x default
Example:
Switch(config-if)# dot1x default
Step 3
Returns to privileged EXEC mode.end
Example:
Switch(config-if)# end
Step 4
Monitoring 802.1x Statistics and Status
Table 28: Privileged EXEC show Commands
PurposeCommand
Displays 802.1x statistics for all portsshow dot1x all statistics
Displays 802.1x statistics for a specific port
show dot1x interface interface-id statistics
Displays the 802.1x administrative and operational
status for a switch
show dot1x all [count | details | statistics |
summary]
Displays the 802.1x administrative and operational
status for a specific port
show dot1x interface interface-id
Table 29: Global Configuration Commands
PurposeCommand
Filters verbose 802.1x authentication messages
(beginning with Cisco IOS Release 12.2(55)SE)
no dot1x logging verbose
For detailed information about the fields in these displays, see the command reference for this release.
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
356 OL-29048-01
Configuring IEEE 802.1x Port-Based Authentication
Monitoring 802.1x Statistics and Status

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
