Page #187 background image
PurposeCommand or Action
Returns to privileged EXEC mode.end
Example:
Switch(config-ext-nacl)# end
Step 5
Verifies your entries.show running-config
Example:
Switch# show running-config
Step 6
(Optional) Saves your entries in the configuration file.copy running-config startup-config
Example:
Switch# copy running-config startup-config
Step 7
When you are creating extended ACLs, remember that, by default, the end of the ACL contains an implicit
deny statement for everything if it did not find a match before reaching the end. For standard ACLs, if you
omit the mask from an associated IP host address access list specification, 0.0.0.0 is assumed to be the mask.
After you create an ACL, any additions are placed at the end of the list. You cannot selectively add ACL
entries to a specific ACL. However, you can use no permit and no deny access-list configuration mode
commands to remove entries from a named ACL.
Being able to selectively remove lines from a named ACL is one reason you might use named ACLs instead
of numbered ACLs.
What to Do Next
After creating a named ACL, you can apply it to interfaces or to VLANs .
Configuring Time Ranges for ACLs
Follow these steps to configure a time-range parameter for an ACL:
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
OL-29048-01 163
Configuring IPv4 ACLs
Configuring Time Ranges for ACLs
