If there is no ACL configured to deny traffic on an interface and no VLAN map is configured, all traffic
is permitted.
•
Each VLAN map consists of a series of entries. The order of entries in an VLAN map is important. A
packet that comes into the switch is tested against the first entry in the VLAN map. If it matches, the
action specified for that part of the VLAN map is taken. If there is no match, the packet is tested against
the next entry in the map.
•
If the VLAN map has at least one match clause for the type of packet (IP or MAC) and the packet does
not match any of these match clauses, the default is to drop the packet. If there is no match clause for
that type of packet in the VLAN map, the default is to forward the packet.
•
Logging is not supported for VLAN maps.
•
When a switch has an IP access list or MAC access list applied to a Layer 2 interface, and you apply a
VLAN map to a VLAN that the port belongs to, the port ACL takes precedence over the VLAN map.
•
If a VLAN map configuration cannot be applied in hardware, all packets in that VLAN are dropped.
VLAN Maps with Router ACLs
To access control both bridged and routed traffic, you can use VLAN maps only or a combination of router
ACLs and VLAN maps. You can define router ACLs on both input and output routed VLAN interfaces, and
you can define a VLAN map to access control the bridged traffic.
If a packet flow matches a VLAN-map deny clause in the ACL, regardless of the router ACL configuration,
the packet flow is denied.
When you use router ACLs with VLAN maps, packets that require logging on the router ACLs are not
logged if they are denied by a VLAN map.
Note
If the VLAN map has a match clause for the type of packet (IP or MAC) and the packet does not match the
type, the default is to drop the packet. If there is no match clause in the VLAN map, and no action specified,
the packet is forwarded if it does not match any VLAN map entry.
VLAN Maps and Router ACL Configuration Guidelines
These guidelines are for configurations where you need to have an router ACL and a VLAN map on the same
VLAN. These guidelines do not apply to configurations where you are mapping router ACLs and VLAN
maps on different VLANs.
If you must configure a router ACL and a VLAN map on the same VLAN, use these guidelines for both router
ACL and VLAN map configuration:
•
You can configure only one VLAN map and one router ACL in each direction (input/output) on a VLAN
interface.
•
Whenever possible, try to write the ACL with all entries having a single action except for the final,
default action of the other type. That is, write the ACL using one of these two forms:
permit... permit... permit... deny ip any any
or
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
152 OL-29048-01
Configuring IPv4 ACLs
VLAN Maps with Router ACLs

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
