SUMMARY STEPS
1.
configure terminal
2.
radius-server key string
3.
radius-server retransmit retries
4.
radius-server timeout seconds
5.
radius-server deadtime minutes
6.
end
7.
show running-config
8.
copy running-config startup-config
DETAILED STEPS
PurposeCommand or Action
Enters the global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 1
Specifies the shared secret text string used between the switch and
all RADIUS servers.
radius-server key string
Example:
Switch(config)# radius-server key
Step 2
The key is a text string that must match the encryption key
used on the RADIUS server. Leading spaces are ignored,
but spaces within and at the end of the key are used. If you
use spaces in your key, do not enclose the key in quotation
marks unless the quotation marks are part of the key.
Note
your_server_key
Switch(config)# key your_server_key
Specifies the number of times the switch sends each RADIUS request
to the server before giving up. The default is 3; the range 1 to 1000.
radius-server retransmit retries
Example:
Switch(config)# radius-server retransmit
Step 3
5
Specifies the number of seconds a switch waits for a reply to a
RADIUS request before resending the request. The default is 5
seconds; the range is 1 to 1000.
radius-server timeout seconds
Example:
Switch(config)# radius-server timeout 3
Step 4
When a RADIUS server is not responding to authentication requests,
this command specifies a time to stop the request on that server.
radius-server deadtime minutes
Example:
Switch(config)# radius-server deadtime
Step 5
This avoids the wait for the request to timeout before trying the next
configured server. The default is 0; the range is 1 to 1440 minutes.
0
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
94 OL-29048-01
Configuring RADIUS
Configuring Settings for All RADIUS Servers

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
