PurposeCommand or Action
(Optional) Generates an RSA key pair. RSA key pairs are required
before you can obtain a certificate for the switch. RSA key pairs
crypto key generate rsa
Example:
Switch(config)# crypto key generate rsa
Step 4
are generated automatically. You can use this command to
regenerate the keys, if needed.
Specifies a local configuration name for the CA trustpoint and enter
CA trustpoint configuration mode.
crypto ca trustpoint name
Example:
Switch(config)# crypto ca trustpoint
Step 5
your_trustpoint
Specifies the URL to which the switch should send certificate
requests.
enrollment url url
Example:
Switch(ca-trustpoint)# enrollment url
Step 6
http://your_server:80
(Optional) Configures the switch to obtain certificates from the
CA through an HTTP proxy server.
enrollment http-proxy host-name port-number
Example:
Switch(ca-trustpoint)# enrollment
Step 7
•
For host-name , specify the proxy server used to get the CA.
•
For port-number, specify the port number used to access the
CA.
http-proxy your_host 49
Configures the switch to request a certificate revocation list (CRL)
to ensure that the certificate of the peer has not been revoked.
crl query url
Example:
Switch(ca-trustpoint)# crl query
ldap://your_host:49
Step 8
(Optional) Specifies that the trustpoint should be used as the
primary (default) trustpoint for CA requests.
primary name
Example:
Switch(ca-trustpoint)# primary
Step 9
•
For name, specify the trustpoint that you just configured.
your_trustpoint
Exits CA trustpoint configuration mode and return to global
configuration mode.
exit
Example:
Switch(ca-trustpoint)# exit
Step 10
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
130 OL-29048-01
Configuring Secure Socket Layer HTTP
Configuring a CA Trustpoint

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
