DETAILED STEPS
PurposeCommand or Action
Enters the global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 1
Enables AAA.aaa new-model
Example:
Switch(config)# aaa new-model
Step 2
Creates an 802.1x authentication method list.
aaa authentication dot1x {default} method1
Step 3
Example:
Switch(config)# aaa authentication dot1x
To create a default list that is used when a named list is not specified
in the authentication command, use the default keyword followed
by the method that is to be used in default situations. The default
method list is automatically applied to all ports.
default group radius
For method1, enter the group radius keywords to use the list of all
RADIUS servers for authentication.
Specifies the port connected to the client that is to be enabled for
IEEE 802.1x authentication, and enter interface configuration mode.
interface interface-id
Example:
Switch(config)# interface
Step 4
gigabitethernet1/0/4
Sets the port to access mode.switchport mode access
Example:
Switch(config-if)# switchport mode access
Step 5
Configures the violation mode. The keywords have these meanings:authentication violation {shutdown | restrict |
protect | replace}
Step 6
• shutdown–Error disable the port.
Example:
Switch(config-if)# authentication
• restrict–Generate a syslog error.
• protect–Drop packets from any new device that sends traffic
to the port.
violation restrict
• replace–Removes the current session and authenticates with
the new host.
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
OL-29048-01 305
Configuring IEEE 802.1x Port-Based Authentication
Configuring 802.1x Violation Modes

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
