PurposeCommand or Action
RADIUS server. The key is a text string that must match the
encryption key used on the RADIUS server.
Always configure the key as the last item in the
radius-server host command syntax because leading spaces
are ignored, but spaces within and at the end of the key are
used. If you use spaces in the key, do not enclose the key
in quotation marks unless the quotation marks are part of
the key. This key must match the encryption used on the
RADIUS daemon.
Note
You can also configure the authentication and encryption key by using
theradius-server key {0string | 7string | string} global configuration
command.
(Optional) Configure the parameters for inaccessible authentication bypass:dot1x critical {eapol | recovery delay
milliseconds}
Step 6
• eapol—Specify that the switch sends an EAPOL-Success message
when the switch successfully authenticates the critical port.
Example:
Switch(config)# dot1x critical eapol
• recovery delaymilliseconds—Set the recovery delay period during
which the switch waits to re-initialize a critical port when a RADIUS
(config)# dot1x critical recovery delay
2000
server that was unavailable becomes available. The range is from 1
to 10000 milliseconds. The default is 1000 milliseconds (a port can
be re-initialized every second).
Specify the port to be configured, and enter interface configuration mode.
interface interface-id
Example:
Switch(config)# interface
gigabitethernet 1/0/1
Step 7
Use these keywords to move hosts on the port if the RADIUS server is
unreachable:
authentication event server dead action
{authorize | reinitialize} vlan vlan-id]
Step 8
Example:
Switch(config-if)# authentication event
• authorize—Move any new hosts trying to authenticate to the
user-specified critical VLAN.
• reinitialize—Move all authorized hosts on the port to the
user-specified critical VLAN.
server dead action
reinitialicze vlan 20
Specifies the voice VLAN for the port. The voice VLAN cannot be the
same as the critical data VLAN configured in Step 6.
switchport voice vlan vlan-id
Example:
Switch(config-if)# switchport voice
Step 9
vlan
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
330 OL-29048-01
Configuring IEEE 802.1x Port-Based Authentication
Configuring 802.1x Inaccessible Authentication Bypass with Critical Voice VLAN

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
