PurposeCommand or Action
Creates a password for the new username.
password password
Example:
Switch(config)# password myswitch
Step 5
Forces the switch to send only multicast EAPOL packets
when it receives either unicast or multicast packets.
dot1x supplicant force-multicast
Example:
Switch(config)# dot1x supplicant force-multicast
Step 6
This also allows NEAT to work on the supplicant switch
in all host modes.
Specifies the port to be configured, and enter interface
configuration mode.
interface interface-id
Example:
Switch(config)# interface gigabitethernet1/0/1
Step 7
Sets the port to trunk mode.switchport trunk encapsulation dot1q
Example:
Switch(config-if)# switchport trunk
Step 8
encapsulation dot1q
Configures the interface as a VLAN trunk port.switchport mode trunk
Example:
Switch(config-if)# switchport mode trunk
Step 9
Configures the interface as a port access entity (PAE)
supplicant.
dot1x pae supplicant
Example:
Switch(config-if)# dot1x pae supplicant
Step 10
Attaches the 802.1x credentials profile to the interface.
dot1x credentials profile-name
Example:
Switch(config-if)# dot1x credentials test
Step 11
Returns to privileged EXEC mode.end
Example:
Switch(config-if)# end
Step 12
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
344 OL-29048-01
Configuring IEEE 802.1x Port-Based Authentication
Configuring a Supplicant Switch with NEAT

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
