Cisco Catalyst 2960-X User Manual

•
Port security option for limiting and identifying MAC addresses of the stations allowed to access the
port
•
VLAN aware port security option to shut down the VLAN on the port when a violation occurs,instead
of shutting down the entire port.
•
Port security aging to set the aging time for secure addresses on a port.
•
Protocol storm protection to control the rate of incoming protocol traffic to a switch by dropping packets
that exceed a specified ingress rate.
•
BPDU guard for shutting down a Port Fast-configured port when an invalid configuration occurs.
•
Standard and extended IP access control lists (ACLs) for defining inbound security policies on Layer 2
interfaces (port ACLs).
•
Extended MAC access control lists for defining security policies in the inbound direction on Layer 2
interfaces.
•
Source and destination MAC-based ACLs for filtering non-IP traffic.
•
DHCP snooping to filter untrusted DHCP messages between untrusted hosts and DHCP servers.
•
IP source guard to restrict traffic on nonrouted interfaces by filtering traffic based on the DHCP snooping
database and IP source bindings
•
Dynamic ARP inspection to prevent malicious attacks on the switch by not relaying invalid ARP requests
and responses to other ports in the same VLAN
•
IEEE 802.1x port-based authentication to prevent unauthorized devices (clients) from gaining access to
the network. These 802.1x features are supported:
◦
Multidomain authentication (MDA) to allow both a data device and a voice device, such as an IP
phone (Cisco or non-Cisco), to independently authenticate on the same IEEE 802.1x-enabled switch
port.
To use MDA, the switch must be running the LAN Base image.Note
◦
Dynamic voice virtual LAN (VLAN) for MDA to allow a dynamic voice VLAN on an
MDA-enabled port.
◦
VLAN assignment for restricting 802.1x-authenticated users to a specified VLAN.
◦
Support for VLAN assignment on a port configured for multi-auth mode. The RADIUS server
assigns a VLAN to the first host to authenticate on the port, and subsequent hosts use the same
VLAN. Voice VLAN assignment is supported for one IP phone.
To use this feature, the switch must be running the LAN Base image. Multi-auth host
mode is not supported in LAN Lite image.
Note
◦
Port security for controlling access to 802.1x ports.
◦
Voice VLAN to permit a Cisco IP Phone to access the voice VLAN regardless of the authorized
or unauthorized state of the port.
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
14 OL-29048-01
Security Features Overview
Security Features Overview

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
