Cisco Catalyst 2960-X User Manual

DETAILED STEPS
PurposeCommand or Action
Enters the global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 1
Specifies the RA Guard policy name and enters RA Guard Policy
configuration mode.
[no]ipv6 nd raguard policy policy-name
Example:
Switch(config)# ipv6 nd raguard policy
example_policy
Step 2
Specifies the role of the device attached to the port. The default is
host.
[no]device-role {host | monitor | router |
switch}
Example:
Switch(config-nd-raguard)# device-role
switch
Step 3
(1–255) Range for Maximum and Minimum Hop Limit values.
[no]hop-limit {maximum | minimum} value
Example:
Switch(config-nd-raguard)# hop-limit
maximum 33
Step 4
Enables filtering of Router Advertisement messages by the Hop Limit
value. A rogue RA message may have a low Hop Limit value
(equivalent to the IPv4 Time to Live) that when accepted by the host,
prevents the host from generating traffic to destinations beyond the
rogue RA message generator. An RA message with an unspecified
Hop Limit value is blocked.
If not configured, this filter is disabled. Configure minimum to block
RA messages with Hop Limit values lower than the value you specify.
Configure maximumto block RA messages with Hop Limit values
greater than the value you specify.
Enables filtering of Router Advertisement messages by the Managed
Address Configuration, or "M" flag field. A rouge RA message with
[no]managed-config-flag {off | on}
Example:
Switch(config-nd-raguard)#
managed-config-flag on
Step 5
an M field of 1 can cause a host to use a rogue DHCPv6 server. If not
configured, this filter is disabled.
On—Accepts and forwards RA messages with an M value of 1, blocks
those with 0.
Off—Accepts and forwards RA messages with an M value of 0, blocks
those with 1.
Matches a specified prefix list or access list.
[no]match {ipv6 access-list list | ra prefix-list
list}
Step 6
Example:
Switch(config-nd-raguard)# match ipv6
access-list example_list
Catalyst 2960-X Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX
OL-29048-01 455
Configuring IPv6 First Hop Security
How to Configure an IPv6 Router Advertisement Guard Policy

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
