Cisco CATALYST 2960 Hardware Installation Guide

1-2
Catalyst 2960 Switch Hardware Installation Guide
OL-7075-09
Chapter 1 Product Overview
Features
The Catalyst 2960-8TC-S, 2960-8TC-L, 2960G-8TC-L, and 2960PD-8TT-L switches are smaller than
the other Catalyst 2960 switches. They can be mounted with a magnet, have security lock slots, and do
not have a fan. See “Catalyst 2960 8-Port Switches” section on page 1-9 for more information. See
Chapter 3, “Switch Installation (8-Port Switches),” for the installation instructions for these switch
models.
These PoE switches comply with Cisco prestandard PoE and IEEE 802.3af:
• Catalyst 2960-24LC-S
• Catalyst 2960-24LT-L
• Catalyst 2960-24PC-L
• Catalyst 2960-24PC-S
• Catalyst 2960-48PST-L
• Catalyst 2960-48PST-S
Catalyst 2960-24LC-S LAN-Lite 24 10/100BASE-TX ports (8 of which are PoE) and 2 dual-purpose ports
Catalyst 2960-8TC-L LAN-Base 8 10/100BASE-TX Ethernet ports and 1 dual-purpose port (no fan or
RPS port)
Catalyst 2960G-8TC-L LAN-Base 7 10/100/100BASE-TX Ethernet ports and 1 dual-purpose port (no fan or
RPS port)
Catalyst 2960PD-8TT-L LAN-Base 8 10/100BASE-TX Ethernet ports and 1 10/100/1000 port that receives
power (no fan, RPS port, or SFP module slot)
Catalyst 2960-24LT-L LAN-Base 24 10/100BASE-TX ports, 8 of which are Power over Ethernet (PoE), and
2 10/100/1000 ports (no SFP module slot)
Catalyst 2960-24PC-L LAN-Base 24 10/100BASE-TX PoE ports and 2 dual-purpose ports
Catalyst 2960-24TC-L LAN-Base 24 10/100BASE-TX Ethernet ports and 2 dual-purpose ports
Catalyst 2960G-24TC-L LAN-Base 20 10/100/1000BASE-T Ethernet ports and 4 dual-purpose ports
Catalyst 2960-24TT-L LAN-Base 24 10/100BASE-TX Ethernet ports and 2 10/100/1000BASE-T copper
uplink ports (no SFP module slot)
Catalyst 2960-48PST-L LAN-Base 48 10/100BASE-TX PoE ports, 2 10/100/1000BASE-T copper ports, and
2 SFP module slots
Catalyst 2960-48TC-L LAN-Base 48 10/100BASE-TX Ethernet ports and 2 dual-purpose ports
Catalyst 2960G-48TC-L LAN-Base 44 10/100/1000BASE-T Ethernet ports and 4 dual-purpose ports
Catalyst 2960-48TT-L LAN-Base 48 10/100BASE-TX Ethernet ports and 2 10/100/1000BASE-T copper
uplink ports (no SFP module slot)
Table 1-1 Catalyst 2960 Switch Model Descriptions (continued)
Switch Model
Supported
Software Image Description

Cisco CATALYST 2960 Specifications

General

Manageable	Yes
Stacking	No
Model	Catalyst 2960 Series Switches
Power over Ethernet (PoE)	Available on some models (IEEE 802.3af)
VLANs	255 active VLANs
Features	QoS
Operating Temperature	32 to 113°F (0 to 45°C)
Relative Humidity	10% to 85% non-condensing
Power Consumption	Varies by model (30W to 400W)
