Cisco CATALYST 2960 Hardware Installation Guide

1-9
Catalyst 2960 Switch Hardware Installation Guide
OL-7075-09
Chapter 1 Product Overview
Front Panel Description
Figure 1-15 Catalyst 2960G-24TC-L Switch Front Panel
Figure 1-16 Catalyst 2960G-48TC-L Switch Front Panel
Catalyst 2960 8-Port Switches
These sections describe the Catalyst 2960 8-port switches:
• Catalyst 2960PD-8TT-L Switch, page 1-9
• Catalyst 2960-8TC-S, Catalyst 2960-8TC-L, and Catalyst 2960G-8TC -L Switches, page 1-10
Catalyst 2960PD-8TT-L Switch
The Catalyst 2960PD-8TT-L (Figure 1-17) switch front panel has a console port, eight 10/100 ports, and
a 10/100/1000 uplink port that can receive power from an upstream PoE switch. The switch can also
receive power from an optional AC power adapter that is connected through the rear panel.
Figure 1-17 Catalyst 2960PD-8TT-L Switch Front Panel
1 10/100/1000 ports 2 Dual-purpose ports
204610
SYST
RPS
STAT
DUPLX
SPEED
MODE
1 2
1 10/100/1000 ports 2 Dual-purpose ports
204611
Catalyst 2
960 SER
IES
MODE
17X
31X
32X
12X
33X
34X
42X
46X
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
1X
2X
15X
18X
16X
12X
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
33
34
35
36
37
38
39
40
41
42
43
44
45 46 47 48
1
2
1 Console port 3 10/100/1000 power input port
2 10/100 ports
Catalyst 2960 Series
SYST
STAT
DPLX
SPD
MODE
CONSOLE
1
1x 2x 3x 4x 5x 6x 7x
8x
PoE INPUT
2
3
1
204643

Cisco CATALYST 2960 Specifications

General

Manageable	Yes
Stacking	No
Model	Catalyst 2960 Series Switches
Power over Ethernet (PoE)	Available on some models (IEEE 802.3af)
VLANs	255 active VLANs
Features	QoS
Operating Temperature	32 to 113°F (0 to 45°C)
Relative Humidity	10% to 85% non-condensing
Power Consumption	Varies by model (30W to 400W)
