Cisco CATALYST 2960 Hardware Installation Guide

B-5
Catalyst 2960 Switch Hardware Installation Guide
OL-7075-09
Appendix B Connector and Cable Specifications
Cable and Adapter Specifications
Table B-1 Fiber-Optic SFP Module Port Cabling Specifications
SFP Module
Wavelength
(nanometers) Fiber Type
Core Size/Cladding
Size (micron)
Modal Bandwidth
(MHz/km)
1
1. Modal bandwidth applies only to multimode fiber.
Cable Distance
100BASE-BX
(GLC-FE-100BX-D
GLC-FE-100BX-U)
1310 TX
1550 RX
SMF G.652
2
— 32,810 feet (10 km)
100BASE-FX
(GLC-GE-100FX)
1310 MMF 50/125
62.5/125
500
500
6,562 feet (2 km)
6,562 feet (2 km)
100BASE-FX
(GLC-FE-100FX)
1310 MMF 50/125
62.5/125
500
500
6,562 feet (2 km)
6,562 feet (2 km)
100BASE-LX
(100BASE-LX10)
1310 SMF G.652
2
— 32,810 feet (10 km)
1000BASE-BX10-D
(GLC-BX-D)
1490 TX
1310 RX
SMF G.652
2
2. A mode-field diameter/cladding diameter = 9 micrometers/125 micrometers
— 32,810 feet (10 km)
1000BASE-BX10-U
(GLC-BX-U)
1310 TX
1490 RX
SMF G.652
2
— 32,810 feet (10 km)
1000BASE-SX
(GLC-SX-MM)
850 MMF 62.5/125
62.5/125
50/125
50/125
160
200
400
500
722 feet (220 m)
902 feet (275 m)
1640 feet (500 m)
1804 feet (550 m)
1000BASE-LX/LH
(GLC-LH-SM)
1310 MMF
3
SMF
3. A mode-conditioning patch cord is required. Using an ordinary patch cord with MMF, 1000BASE-LX/LH SFP modules, and a short link distance
can cause transceiver saturation, resulting in an elevated bit error rate (BER). When using the LX/LH SFP module with 62.5-micron diameter MMF,
you must also install a mode-conditioning patch cord between the SFP module and the MMF cable on both the sending and receiving ends of the
link. The mode-conditioning patch cord is required for link distances greater than 984 feet (300 m).
62.5/125
50/125
50/125
G.652
2
500
400
500
—
1804 feet (550 m)
1804 feet (550 m)
1804 feet (550 m)
32,810 feet (10 km)
1000BASE-ZX
(GLC-ZX-SM
1550 SMF G.652
2
— 43.4 to 62 miles
(70 to 100 km)
4
4. 1000BASE-ZX SFP modules can send data up to 62 miles (100 km) by using dispersion-shifted SMF or low-attenuation SMF; the distance depends
on the fiber quality, the number of splices, and the connectors.
CWDM 1470, 1490,
1510, 1530,
1550, 1570,
1590, 1610
SMF G.652
2
— 62 miles (100 km)

Cisco CATALYST 2960 Specifications

General

Manageable	Yes
Stacking	No
Model	Catalyst 2960 Series Switches
Power over Ethernet (PoE)	Available on some models (IEEE 802.3af)
VLANs	255 active VLANs
Features	QoS
Operating Temperature	32 to 113°F (0 to 45°C)
Relative Humidity	10% to 85% non-condensing
Power Consumption	Varies by model (30W to 400W)
