Figure 11: Supervisor PIC

NME ports7Ejector lever1

Console port8Timing port (1 PPS)2

Auxiliary port9Timing port (10 MHz)3

Captive screws10GPS port4

LEDs11DTI ports5

SFP+ ports12CM/DTP port6

Table 11: Physical Specifications of the Supervisor PIC

ValueUnit

7.82 in (19.86 cm)Depth

11.8 in (29.97 cm)Width

2.8 in (7.11 cm)Height

6 lb (2.72 kg)Maximum weight
