Configurable Parameters
The following table defines the configurable parameters for the EDFA.
Param
Name
Products
Function
DefaultV
alue
Min
Typical
Max
Step
Unit
Mode
All
Sets operating
mode of amplifier
[A]
na
na
na
Constant
Gain (0)
Constant
Power (1)
na
Enable
All
Enables or
disables amplifier
Off(0)
na
na
na
Off(0)
On(1)
na
Set
Power
BCST 17
Sets optical output
level [B]
17
14
17
17
0.1
dBm
BCST 20
Sets optical output
level [B]
20
17
20
20
0.1
dBm
BCST 22
Sets optical output
level [B]
22
19
22
22
0.1
dBm
GF 17
Sets optical output
level [B]
17
14
17
17
0.1
dBm
GF 21
Sets optical output
level [B]
21
18
21
21
0.1
dBm
Set Gain
BCST 17
Sets gain level in
Constant Gain
Mode [A][B]
12
10
12
14
0.1
dB
BCST 20
Sets gain level in
Constant Gain
Mode [A][B]
15
13
15
17
0.1
dB
BCST 22
Sets gain level in
Constant Gain
Mode [A][B]
17
15
17
19
0.1
dB
GF 17H
[A]
12
10
12
14
0.1
dB
GF 21H
[A]
16
14
16
18
0.1
dB
GF 17L
[A]
7
5
7
9
0.1
dB
GF 21L
[A]
11
9
11
13
0.1
dB
[A] For the Broadcast amplifier, the default is Constant Power. For the Narrowcast
amplifier, the default is Constant Gain.
[B] In Constant Power mode only.
