Cisco GS7000 Installation And Configuration Guide

Optical Amplifier (EDFA) Modules
OL-29936-01 67
32 Wavelength System
A 32 wavelength system is designed to have a maximum capacity of 32 optical
channels. The actual number of optical channels at the deployment can be 32 or less.
Model
Set Gain (Gc)
Composite Input (P
IN/C
)
(1λ  32 λ)
Composite Output (P
OUT/C
)
(1λ  32 λ)
GS-EDFA-GF-
17L-SA
5 dB
6 dB
7 dB*
8 dB
9 dB
-3 dBm  12 dBm
-4 dBm  11 dBm
-5 dBm  10 dBm
-6 dBm  9 dBm
-7 dBm  8 dBm
2 dBm  17 dBm
2 dBm  17 dBm
2 dBm  17 dBm
2 dBm  17 dBm
2 dBm  17 dBm
GS-EDFA-GF-
17H-SA
10 dB
11 dB
12 dB*
13 dB
14 dB
-8 dBm  7 dBm
-9 dBm  6 dBm
-10 dBm  5 dBm
-11 dBm  4 dBm
-12 dBm  3 dBm
2 dBm  17 dBm
2 dBm  17 dBm
2 dBm  17 dBm
2 dBm  17 dBm
2 dBm  17 dBm
GS-EDFA-GF-
21L-SA
9 dB
10 dB
11 dB*
12 dB
13 dB
-3 dBm  12 dBm
-4 dBm  11 dBm
-5 dBm  10 dBm
-6 dBm  9 dBm
-7 dBm  8 dBm
6 dBm  21 dBm
6 dBm  21 dBm
6 dBm  21 dBm
6 dBm  21 dBm
6 dBm  21 dBm
GS-EDFA-GF-
21H-SA
14 dB
15 dB
16 dB*
17 dB
18 dB
-8 dBm  7 dBm
-9 dBm  6 dBm
-10 dBm  5 dBm
-11 dBm  4 dBm
-12 dBm  3 dBm
6 dBm  21 dBm
6 dBm  21 dBm
6 dBm  21 dBm
6 dBm  21 dBm
6 dBm  21 dBm
* Default gain setting
