Cisco RV042G Administration Guide

VPN
Introduction to VPNs
Cisco Small Business RV0xx Series Routers Administration Guide 124
9
You will need to configure this router with the specific IPsec policies required for
the IPsec client. You also will need to install and configure the IPsec client
software on the users’ computers.
NOTE Consider two other remote access options: Remote Access with Cisco
QuickVPN, page 125 and Remote Access with PPTP, page 125.
The following is an example of a client-to-gateway VPN. A business traveler
connects to the Internet from her hotel room. Her notebook computer has VPN
client software that is configured with her office’s VPN settings. She accesses the
VPN client software and connects to the VPN router at the central office. Using the
VPN, she now has a secure connection to the central office’s network, as if she
were physically connected.
Configuration tasks:
1. Use the VPN > Client to Gateway page to configure the VPN tunnel with the
settings required by the third-party client, such as TheGreenbow. For
instructions, see Setting Up a Remote Access Tunnel for VPN Clients (Client
To Gateway), page 139.
2. Install the client software on the users’ computers.
199469
Outside
209.165.200.226
DNS Server
WINS Server
192.168.1.30
Personal Computer
Using VPN Software Client
Personal Computer
Using VPN Software Client
Personal Computer
Using VPN Software Client
Inside
192.168.1.1
RV0xx
router
Internet
Internal
network

Cisco RV042G Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	6
Routing protocols	IP, RIP-1, RIP-2
Supported network protocols	PPTP, L2TP, IPSec, PPPoE, DHCP
VPN support	PPTP, Layer 2 Tunneling Protocol (L2TP), IPsec, Dead peer detection (DPD), Internet Key Exchange (IKE), split DNS, VPN backup
Firewall security	Stateful packet inspection (SPI) firewall
Security algorithms	3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, HTTPS, IPSEC
VPN tunnels quantity	50
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC Class B, CE Class B, UL, cUL, CB
Input current	1 A
Output voltage	12 V
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No

Weight and Dimensions

Depth	200 mm
Width	130 mm
Height	38.5 mm
Weight	600 g
