Cisco RV042G Administration Guide

1
Cisco Small Business RV0xx Series Routers Administration Guide 7
Introduction
Thank you for choosing a RV0xx Series VPN Router. This guide provides complete
information to help you configure and manage your router. This chapter includes
information to help you get started using your router. Refer to these topics:
• RV0xx Series Router Features, page 7
• Mounting Options, page 12
• Connecting the Equipment, page 15
• Getting Started with the Configuration, page 16
• Features of the User Interface, page 18
RV0xx Series Router Features
Cisco RV0xx Series dual WAN and multi-WAN VPN routers offer highly secure,
high-performance, reliable connectivity. All of these routers can support a second
Internet connection to ensure continuous connectivity or to increase available
bandwidth and balance traffic. Three models are available. A comparison is
provided below.
NOTE RV042, RV042G, and RV082 have one dedicated Internet port and a DMZ/Internet
port. RV016 has two dedicated Internet ports, one dedicated DMZ port, and five
dual-function ports that can be configured as LAN or Internet ports.
Model LAN
Ports
WAN/DMZ
Ports
RV042 and RV042G 42
RV082 82
RV016 8-13 2-7 Internet
1DMZ

Cisco RV042G Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	6
Routing protocols	IP, RIP-1, RIP-2
Supported network protocols	PPTP, L2TP, IPSec, PPPoE, DHCP
VPN support	PPTP, Layer 2 Tunneling Protocol (L2TP), IPsec, Dead peer detection (DPD), Internet Key Exchange (IKE), split DNS, VPN backup
Firewall security	Stateful packet inspection (SPI) firewall
Security algorithms	3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, HTTPS, IPSEC
VPN tunnels quantity	50
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC Class B, CE Class B, UL, cUL, CB
Input current	1 A
Output voltage	12 V
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No

Weight and Dimensions

Depth	200 mm
Width	130 mm
Height	38.5 mm
Weight	600 g
