Cisco RV042G Administration Guide

IPv6 Transition
Cisco Small Business RV0xx Series Routers Administration Guide 61
3
IPv6 Transition
When Dual-Stack IP is enabled on the Network > Setup page, a 6to4 tunnel is
enabled by default for IPv6 packets via 6to4 source/destination addressing
exchange. This feature allows the router to establish auto-tunnel in IPv4 network
(or a real IPv4 Internet connection) across two independent IPv6 networks. Use
the Setup > IPv6 Transition page to disable or enable this feature.
To open this page: Click Setup > IPv6 Transition in the navigation tree.
Check the box to enable the 6to4 tunnel, or uncheck the box to disable it.
NOTE Before navigating away from this page, click Save to save your settings, or click
Cancel to undo them. Any unsaved changes are abandoned.
Next steps: For a typical deployment, such as setting up a 6to4 tunnel between
your RV0xx Series router and a Cisco RV Series router at another site, you also
should complete the tasks listed below.
• On the DHCP->Router Advertisement page, enable managed RA flags to
support auto-configuration of connected devices. Verify that your IPv6
devices acquire 6to4 prefixes. The prefixes will be in the following format:
2002:<your WAN IP in hexadecimal format>::)
• Temporarily disable the router firewall for testing of your 6to4 tunnel. On the
Firewall > General page, choose Disable. To test the tunnel, attempt to ping
an IPv6 address at the remote location.
• After verifying the tunnel as described above, enable the firewall and add
access rules on the Firewall > Access Rules page. For example, add a rule
to allow all traffic through the WAN interface where the source is a single IP

Cisco RV042G Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	6
Routing protocols	IP, RIP-1, RIP-2
Supported network protocols	PPTP, L2TP, IPSec, PPPoE, DHCP
VPN support	PPTP, Layer 2 Tunneling Protocol (L2TP), IPsec, Dead peer detection (DPD), Internet Key Exchange (IKE), split DNS, VPN backup
Firewall security	Stateful packet inspection (SPI) firewall
Security algorithms	3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, HTTPS, IPSEC
VPN tunnels quantity	50
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC Class B, CE Class B, UL, cUL, CB
Input current	1 A
Output voltage	12 V
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No

Weight and Dimensions

Depth	200 mm
Width	130 mm
Height	38.5 mm
Weight	600 g
