Cisco RV042G Administration Guide

Cisco QuickVPN for Windows
Cisco QuickVPN Client Installation and Configuration
Cisco Small Business RV0xx Series Routers Administration Guide 168
C
Cisco QuickVPN Client Installation and Configuration
For each QuickVPN client, complete the following tasks:
STEP 1 To download QuickVPN, complete the following tasks:
a. Start a web browser, and enter the following address: www.cisco.com/go/
software
b. In the Software Download Search box, enter: QuickVPN
c. Click Go.
d. In the search results, click the link for your router.
e. Follow the on-screen instructions to download the QuickVPN client.
STEP 2 To install the client certificate, save the client certificate to the directory where the
QuickVPN program is installed.
Example: C:\Program Files\Cisco Small Business\QuickVPN Client\
NOTE: QuickVPN can be used without a certificate installed on the PC. The user
will see a security warning but can use QuickVPN without this added security.
Using the Cisco QuickVPN Software
NOTE: Optionally, an SSL certificate can be installed on the PC for extra security; if
this certificate is not installed, you can still use QuickVPN, but you will see a pop-
up warning during this process.
For each QuickVPN client, follow these instructions:
STEP 1 Double-click the Cisco QuickVPN software icon on your desktop or in the system
tray.
STEP 2 When the QuickVPN Login page appears, enter the following information:
• Profile Name: Enter a name for your profile.
• Username: Enter the username assigned to you.
• Password: Enter the password assigned to you.

Cisco RV042G Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	6
Routing protocols	IP, RIP-1, RIP-2
Supported network protocols	PPTP, L2TP, IPSec, PPPoE, DHCP
VPN support	PPTP, Layer 2 Tunneling Protocol (L2TP), IPsec, Dead peer detection (DPD), Internet Key Exchange (IKE), split DNS, VPN backup
Firewall security	Stateful packet inspection (SPI) firewall
Security algorithms	3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, HTTPS, IPSEC
VPN tunnels quantity	50
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC Class B, CE Class B, UL, cUL, CB
Input current	1 A
Output voltage	12 V
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No

Weight and Dimensions

Depth	200 mm
Width	130 mm
Height	38.5 mm
Weight	600 g
