Cisco RV042G Administration Guide

Introduction
Getting Started with the Configuration
Cisco Small Business RV0xx Series Routers Administration Guide 16
1
• RV016: Connect an Ethernet cable from the Internet 2 port to a second
broadband network device.
STEP 4 To connect a computer or server that will be a DMZ host:
• RV042, RV042G, and RV082: Connect an Ethernet cable from the DMZ/
Internet port to the DMZ host.
• RV016: Connect an Ethernet cable from the DMZ port to the DMZ host.
STEP 5 To connect other network devices, such as computers, print servers, or Ethernet
switches, connect an Ethernet cable from a numbered LAN port to the network
device.
STEP 6 Power on the broadband network device(s).
STEP 7 Use the power adapter (RV042 and RV042G) or the power cable (RV082 and
RV016) to connect the router to a power outlet. The System status light is green.
STEP 8 Power on the other network devices.
Getting Started with the Configuration
STEP 1 Connect a computer to a numbered LAN port on the router. Your PC will become a
DHCP client of the router and will receive an IP address in the 192.168.1.x range.
STEP 2 Start a web browser. To use the configuration utility, you need a PC with Internet
Explorer (version 6 and higher), Firefox, or Safari (for Mac).
STEP 3 In the address bar, enter the default IP address of the router: 192.168.1.1
STEP 4 When the login page appears, enter the default user name admin and the default
password admin (lowercase).
STEP 5 Click Login. The System Summary page appears.
The router’s default settings are sufficient for many small businesses. Your Internet
Service Provider may require additional settings. On the System Summary page,
check the WAN Status to see if the router was able to receive an IP Address. If not,
continue to the next step.

Cisco RV042G Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	6
Routing protocols	IP, RIP-1, RIP-2
Supported network protocols	PPTP, L2TP, IPSec, PPPoE, DHCP
VPN support	PPTP, Layer 2 Tunneling Protocol (L2TP), IPsec, Dead peer detection (DPD), Internet Key Exchange (IKE), split DNS, VPN backup
Firewall security	Stateful packet inspection (SPI) firewall
Security algorithms	3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, HTTPS, IPSEC
VPN tunnels quantity	50
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC Class B, CE Class B, UL, cUL, CB
Input current	1 A
Output voltage	12 V
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No

Weight and Dimensions

Depth	200 mm
Width	130 mm
Height	38.5 mm
Weight	600 g
