Cisco RV042G Administration Guide

Logging System Statistics
Viewing the System Log
Cisco Small Business RV0xx Series Routers Administration Guide 157
10
Viewing the System Log
Use the Log > System Log page to display statistics about all of the router’s ports
(LAN and WAN ports).
To open this page: click Log > System Statistics in the navigation tree.
Statistics appear for each interface, such as LAN, WAN1, WAN2 or DMZ. You can
click Refresh to update the data.
For each port, the following statistics are listed:
• Device Name: The port ID, such as eth0, eth1, eth2, and so on
• Status: The port status. Depending on the interface type, the status may be
Connected, Disconnected, Enabled, or Disabled.
• IP Address: The IP address of the interface
• MAC Address: The MAC of the connected device
• Subnet Mask: The subnet mask
• Default Gateway: The default gateway
• DNS: The DNS server for DNS name resolution
• Received Packets: The number of packets received through this interface
• Sent Packets: The number of packets sent through this interface
• Total Packet s: The total number of packets sent and received through this
interface

Cisco RV042G Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	6
Routing protocols	IP, RIP-1, RIP-2
Supported network protocols	PPTP, L2TP, IPSec, PPPoE, DHCP
VPN support	PPTP, Layer 2 Tunneling Protocol (L2TP), IPsec, Dead peer detection (DPD), Internet Key Exchange (IKE), split DNS, VPN backup
Firewall security	Stateful packet inspection (SPI) firewall
Security algorithms	3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, HTTPS, IPSEC
VPN tunnels quantity	50
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC Class B, CE Class B, UL, cUL, CB
Input current	1 A
Output voltage	12 V
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No

Weight and Dimensions

Depth	200 mm
Width	130 mm
Height	38.5 mm
Weight	600 g
