Cisco RV042G Administration Guide

Setup
Cloning a MAC Address for the Router
Cisco Small Business RV0xx Series Routers Administration Guide 53
3
Cloning a MAC Address for the Router
Some ISPs require that you register a MAC address, which is a 12-digit code
assigned to a unique piece of hardware for identification. If you previously
registered another MAC address with your ISP, you can use the Setup > MAC
Address Clone page to “clone” that address to your Cisco RV0xx Series router. By
using this process, you don’t have to call your ISP to change the registered MAC
address.
To open this page: Click Setup > MAC Address Clone in the navigation tree.
This page displays the current settings. Click the Edit icon to display the Edit MAC
Address Clone page. For more information, see Editing the MAC Address Clone
Settings, page 54.

Cisco RV042G Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	6
Routing protocols	IP, RIP-1, RIP-2
Supported network protocols	PPTP, L2TP, IPSec, PPPoE, DHCP
VPN support	PPTP, Layer 2 Tunneling Protocol (L2TP), IPsec, Dead peer detection (DPD), Internet Key Exchange (IKE), split DNS, VPN backup
Firewall security	Stateful packet inspection (SPI) firewall
Security algorithms	3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, HTTPS, IPSEC
VPN tunnels quantity	50
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC Class B, CE Class B, UL, cUL, CB
Input current	1 A
Output voltage	12 V
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No

Weight and Dimensions

Depth	200 mm
Width	130 mm
Height	38.5 mm
Weight	600 g
