VPN
Introduction to VPNs
Cisco Small Business RV0xx Series Routers Administration Guide 123
9
Site to Site VPN (Gateway To Gateway)
In a site-to-site or gateway-to-gateway VPN, a VPN router at one office connects
to a VPN router at a remotely located office. Client devices can access network
resources as if they were all at the same site. This model can be used for multiple
users at a remote office.
In the following example, the main office (Site A) and a remote office (Site B) are
connected by a VPN tunnel. Users at both sites have access to the network
resources at both sites.
Configuration tasks:
Use the VPN > Gateway to Gateway page to configure the VPN tunnel. For
instructions, see Setting Up a Gateway to Gateway (Site to Site) VPN,
page 130. For more details and examples, see Appendix D, “Configuring a
Gateway-to-Gateway VPN Tunnel Between RV0xx Series Routers.”
Remote Access (Client To Gateway)
In a remote access or client-to-gateway VPN, a computer with VPN client software
connects to a VPN router. For this scenario, you can install third-party VPN client
software on the users’ computers. Alternatively, a VPN tunnel can be accessed
from any computer with the built-in IPSec Security Manager (Windows 2000,
Windows XP, and Windows 7).
1
99468
Site A
RV016
router
RV042
router
Site B
Inside
192.168.1.1/24
Outside
209.165.200.226/24
Outside
209.165.200.236/24
Inside
192.168.2.1/24
Personal
computers
Personal
computers
Printer Printer
Internet

Cisco RV042G Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	6
Routing protocols	IP, RIP-1, RIP-2
Supported network protocols	PPTP, L2TP, IPSec, PPPoE, DHCP
VPN support	PPTP, Layer 2 Tunneling Protocol (L2TP), IPsec, Dead peer detection (DPD), Internet Key Exchange (IKE), split DNS, VPN backup
Firewall security	Stateful packet inspection (SPI) firewall
Security algorithms	3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, HTTPS, IPSEC
VPN tunnels quantity	50
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC Class B, CE Class B, UL, cUL, CB
Input current	1 A
Output voltage	12 V
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No

Weight and Dimensions

Depth	200 mm
Width	130 mm
Height	38.5 mm
Weight	600 g
