Cisco RV042G Administration Guide

Bandwidth Management
Creation of New Bandwidth Management Rules
Cisco Small Business RV0xx Series Routers Administration Guide 188
F
e. In the Max. Rate field, enter the maximum rate for the maximum bandwidth. For
example, you can set a maximum rate of 80 kbit/sec.
f. Select Enable to enable this rule.
g. After you have set up the rule, click Add to list.
STEP 3 Set up an upstream rule for Vonage 2.
a. Select Vonage 2 from the
Service drop-down menu.
b. Enter the IP address or range you need to control. To include all internal IP
addresses, keep the default, 0.
c. From the
Direction drop-down menu, select Upstream for outbound traffic.
d. In the
Min. Rate field, enter the minimum rate for the guaranteed bandwidth. For
example, you can set a minimum rate of 40 kbit/sec.
e. In the
Max. Rate field, enter the maximum rate for the maximum bandwidth. For
example, you can set a maximum rate of 80 kbit/sec.
f. Select Enable to enable this rule.
g. After you have set up the rule, click Add to list.
STEP 4 Set up a downstream rule for Vonage 2.
a. Select Vonage 2 from the
Service drop-down menu.
b. Enter the IP address or range you need to control. To include all internal IP
addresses, keep the default, 0.
c. From the
Direction drop-down menu, select Downstream for inbound traffic.
d. In the
Min. Rate field, enter the minimum rate for the guaranteed bandwidth. For
example, you can set a minimum rate of 40 kbit/sec.
e. In the
Max. Rate field, enter the maximum rate for the maximum bandwidth. For
example, you can set a maximum rate of 80 kbit/sec.
f. Select Enable to enable this rule.
g. After you have set up the rule, click Add to list.
STEP 5 Click Save.

Cisco RV042G Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	6
Routing protocols	IP, RIP-1, RIP-2
Supported network protocols	PPTP, L2TP, IPSec, PPPoE, DHCP
VPN support	PPTP, Layer 2 Tunneling Protocol (L2TP), IPsec, Dead peer detection (DPD), Internet Key Exchange (IKE), split DNS, VPN backup
Firewall security	Stateful packet inspection (SPI) firewall
Security algorithms	3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, HTTPS, IPSEC
VPN tunnels quantity	50
Authentication method	SHA-1, MD5
MAC address filtering	-
Certification	FCC Class B, CE Class B, UL, cUL, CB
Input current	1 A
Output voltage	12 V
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Product color	Black
Rack mounting	No

Weight and Dimensions

Depth	200 mm
Width	130 mm
Height	38.5 mm
Weight	600 g
