Managing the Bandwidth Settings
Cisco Small Business RV0xx Series Routers Administration Guide 82
5
• Priority: Choose this option to manage the bandwidth by identifying high-
priority and low-priority services.
Select an Interface. Add the services that are subject to bandwidth management.
• To add a new service to the list: Enter the settings as described below,
and then click Add to List. You can add up to 100 services.
- Service: Select a service to manage. If a service is not listed, you can
click Service Management to add a service. For more information, see
Adding a service, page 83.
- IP (for Rate Control only): Enter the IP address or range you need to
control. To include all internal IP addresses, keep the default setting.
- Direction: Select Upstream for outbound traffic, or select Downstream
for inbound traffic.
- Min. Rate (for Rate Control only): Enter the minimum rate (Kbit/sec) for
the guaranteed bandwidth.
- Max. Rate (for Rate Control only): Enter the maximum rate (Kbit/sec) for
the guaranteed bandwidth.
- Priority (for Priority management only): Choose the priority for this
service: High or Low.
- Enable: Check the box to enable this feature, or uncheck the box to
disable this feature.
• To add another service to the list: Enter the information, and then click Add
to list.
• To modify a service in the list: Click the entry that you want to modify. The
information appears in the text fields. Make the changes, and then click
Update. If you do not need to make changes, you can click Add New to de-
select the entry and clear the text fields.
• To delete an entry from the list: Click the entry that you want to delete, and
then click Delete. To select a block of entries, click the first entry, hold down
the Shift key, and then click the final entry in the block. To select individual
entries, press the Ctrl key while clicking each entry. To de-select an entry,
press the Ctrl key while clicking the entry.
