Cisco SG200 Series User Manual

Port Management
Green Ethernet
Cisco Small Business SG200 Series 8-port Smart Switch 102
4
- Link up—There is activity on the link.
- Admin Down—Energy detect mode is administratively disabled.
STEP 2 Select the port to configure and click Edit.
STEP 3 Select Energy Detect to administratively enable Energy Detect on the port.
STEP 4 Click Apply to save any changes to the Running Configuration.

Cisco SG200 Series Specifications

General

Model	SG200 Series
Layer	Layer 2
Type	Smart Switch
Port Type	Gigabit Ethernet
Form Factor	Desktop or Rack-mountable
Management	SNMP
VLAN Support	Yes
Quality of Service (QoS)	Yes
Security	Yes
MAC Address Table	8K
Jumbo Frame Support	Yes
Operating Temperature	0 to 40°C (32 to 104°F)
Storage Temperature	-4°F to 158°F (-20°C to 70°C)
Humidity	10% to 90% non-condensing
Power Supply	Internal
Ports	8
Switching Capacity	16 Gbps
Forwarding Rate	11.9 Mpps
