Administration
File Management
Cisco Small Business SG200 Series 8-port Smart Switch 71
3
Downloading an Image or Boot Code File From the System
Boot Prompt
You can download and install a new image or boot code file at the system boot
prompt using the TFTP and XMODEM protocols. This process may be necessary
when the application software does not execute due to a corrupted software
image or boot code file and, as a result, you cannot access the CLI or web-based
interface utilities for downloading and installing new software.
If the switch is connected to a network, you can obtain IP information for the switch
via DHCP, and then use TFTP to download the file.
If no network connection is available, and the switch is connected through its serial
console port to a management station, you can use the XMODEM protocol to
download the file.
NOTE This process requires a management system that is connected to the serial
console port on the switch and has a terminal emulation program, such as Tera Term
or HyperTerminal. Configure the utility with the following parameters:
• 115200 bits per second
• 8 data bits
• no parity
• 1 stop bit
• no flow control
See your product Quick Start Guide for more information on setting up the
console port connection.
Downloading an Image or Boot Code File Using TFTP
To download a software image or boot code file using TFTP at the boot prompt:
STEP 1 Using a terminal emulation program, open a serial connection between the switch
and the management system connected to the switch console port.
STEP 2 Physically connect switch port e1 to the network.
STEP 3 Power up the switch.
STEP 4 Stop the firmware load by pressing and holding <Ctrl>+C as the switch boots up.
The boot-level command prompt displays:
CFE>
