Viewing Statistics
System Summary
Cisco Small Business SG200 Series 8-port Smart Switch 21
2
• Port—The Internet Assigned Numbers Authority (IANA) port number for the
service.
• IP Address—The IP address, if any, of a remote device that is connected to
this service on the switch.
• Remote Port—The IANA port number of any remote device communicating
with this service.
• State—The state of the service. For UDP, only connections in the Active state
display in the table. In the Active state, a connection is established between
the switch and a client or server. The TCP states are:
- Listen—The service is listening for connection requests.
- Active—A connection session is established and packets are being
transmitted and received.
- Established—A connection session is established between the switch
and a server or client, depending on each device’s role with respect to
this protocol.
Configuring System Settings
To configure the system settings:
STEP 1 Click Status and Statistics > System Summary. The System Summary page
opens.
STEP 2 Click Edit to modify the following settings:
• System Location—Enter the location where the switch is physically located.
• System Contact—Enter the name of a contact person.
• Hostname—Enter the hostname. Use only letters, digits, and hyphens. Host
names cannot begin or end with a hyphen. No other symbols, punctuation
characters, or blank spaces are permitted (as specified in RFC1033,
RFC1034, and RFC1035). The default hostname is the word switch
followed by the last three octets of the base MAC address. For example, a
switch with a MAC address of 010203040506 has the default hostname
switch040506.
STEP 3 Click Apply. Your changes are saved to the Running Configuration.
