VLAN Management
Voice and Media
Cisco Small Business SG200 Series 8-port Smart Switch 116
5
When a port is LLDP-MED enabled with network policy, the switch will advertise
its Media VLANs in the LLDP-MED network policy TLVs out to the port. When a
LLDP Media Endpoint is discovered, the switch will install the Media VLAN at the
corresponding port. You can enable LLDP-MED and networking policy in the
Administration > Discovery - LLDP pages.
Media VLAN is enabled and disabled globally. Each application and its Media
VLAN is configured on a per-port basis. For example, Guest Voice can be on
Media VLAN 1 on interface g1, but can be on Media VLAN 10 on interface g2.
The Media VLAN Interface Settings Table displays each media traffic type that
can be enabled, and shows its status and settings on the selected port.
To configure Media VLAN applications:
STEP 1 Click VLAN management > Voice and Media > Media VLAN in the navigation
window.
STEP 2 Select Enable for Admin Mode to globally enable this feature on the switch, and
then click Apply.
STEP 3 Select an interface to configure from the Interface list.
CAUTION Ports that are members of a LAG cannot be enabled for Media VLAN applications
(see Configuring LAGs).
STEP 4 From the Application list, select the media traffic type to configure:
• Voice
• Voice Signaling
• Guest Voice
• Guest Voice Signaling
• Softphone Voice
• Video Conferencing
• Streaming Video
• Video Signaling
STEP 5 Click Edit.
