Cisco SPA 508G Administration Guide

Configuring Security, Quality, and Network Features
Configuring Domain and Internet Settings
Cisco Small Business SPA 300 Series, SPA 500 Series, and WIP310 IP Phone Administration Guide 130
5
STEP 5 Click Submit All Changes.
NOTE For the Cisco SPA 301 and Cisco SPA501G, can be configured using the IVR. See
the “Using IVR on the Cisco SPA 301 and Cisco SPA 501G IP Phone” section on
page 19.
Setting a Static IP Address
If you configured Static IP as the internet connection type:
STEP 1 Log in to the configuration utility.
STEP 2 Click Admin Login and advanced.
STEP 3 Click the System tab.
STEP 4 Configure the following fields:
• Static IP Address—Enter the static IP address of the phone.
• Netmask—Enter the subnet mask of the phone.
• Gateway—Enter the IP address of the gateway.
For the SPA 525G
/525G2, you also have the following fields available:
• LAN MTU—LAN Maximum Transmission Unit size. Default value: 1500.
• Duplex Mode—Choose one of the following to configure the speed/duplex
for the phone’s Ethernet ports:
- Auto
- 10MBps/Duplex
- 10MBps/Half
- 100Mbps/Duplex
- 100MBps/Half
STEP 5 Click Submit All Changes.
NOTE For the Cisco SPA 301 and Cisco SPA501G, can be configured using the IVR. See
the “Using IVR on the Cisco SPA 301 and Cisco SPA 501G IP Phone” section on
page 19.

Cisco SPA 508G Specifications

General

Speakerphone	Yes
Dialer location	Base
Mac compatibility	No
Ethernet LAN (RJ-45) ports	2
Display resolution	128 x 64 pixels
Display number of colors	Monochrome
Headphone connectivity	2.5 mm

Weight and Dimensions

Depth	212 mm
Width	214 mm
Height	44 mm
Weight	900 g
