Cisco SPA 508G Administration Guide

Configuring Lines and Extensions
Configuring Lines
Cisco Small Business SPA 300 Series, SPA 500 Series, and WIP310 IP Phone Administration Guide 29
2
STEP 1 Log in to the configuration utility.
STEP 2 Click Admin Login.
STEP 3 Click advanced.
STEP 4 Click the Attendant Console tab. In the General section, under Server Type ,
choose RFC3265_4236.
STEP 5 Click the Phone tab.
STEP 6 Choose the line key to configure (line 5 in this example):
a. From the
Extension drop down list, choose Disabled.
b. From the
Share Call Appearance drop-down list, choose private.
c. Enter the following string in the Extended Function field:
fnc=prk;sub=05@domain.com
where:
- fnc: function
- prk: call park
- sub: call park orbit, or location where the call is parked. Valid value range
is from 01 through 10. In this example, 5 is used.
- domain.com: phone domain, usually the same as the “proxy” value in the
Ext 1 tab. You can also use fnc=prk;sub=05@$PROXY to use this value.
STEP 7 Click Submit All Changes.
Configuring Unused Line Keys to Access Services
On the Cisco SPA 300 Series or Cisco SPA 500 Series IP Phones, unused or idle
phone lines can also be configured to access services, such as the following:
• XML services
• MP3 player (Cisco SPA 525G/525G2)
• Weather (RSS)
• News (RSS)

Cisco SPA 508G Specifications

General

Speakerphone	Yes
Dialer location	Base
Mac compatibility	No
Ethernet LAN (RJ-45) ports	2
Display resolution	128 x 64 pixels
Display number of colors	Monochrome
Headphone connectivity	2.5 mm

Weight and Dimensions

Depth	212 mm
Width	214 mm
Height	44 mm
Weight	900 g
