Cisco SPA 508G Administration Guide

Configuring Lines and Extensions
Configuring Extensions
Cisco Small Business SPA 300 Series, SPA 500 Series, and WIP310 IP Phone Administration Guide 33
2
STEP 5 Click Submit All Changes.
For more information on LEDs, see the “Creating an LED Script” section on
page 199.
Configuring Extensions
STEP 1 Log in to the configuration utility.
STEP 2 Click Admin Login and advanced.
STEP 3 Click the Ext <number> tab for the extension you want to configure.
STEP 4 In the General section, make sure that Line Enable is set to yes.
You can configure many parameters differently for different extensions. These
parameters are grouped on the Ext <number> tab. These parameters are
explained in other sections of this document:
• NAT, Network, and SIP Settings—Chapter 4, “Configuring SIP, SPCP, and
NAT.”
• Call Feature Settings—Chapter 3, “Customizing Cisco SPA and Wireless
IP Phones.”
Register Failed LED LED pattern when the corresponding extension has failed to
register with the proxy server. Leaving this entry blank
indicates the default value of c=a.
Disabled LED LED pattern when the Call Appearance is disabled (not
available for any incoming or outgoing call). Leaving this entry
blank indicates the default value of c=o.
Registering LED Appears when the corresponding extension tries to register
with the proxy server.
Defaults to blanks (c=r;p=s).
Call Back Active LED Indicates Call Back operation is currently active on this call.
Defaults to blank (c=r;p=s).
Parameters Description

Cisco SPA 508G Specifications

General

Speakerphone	Yes
Dialer location	Base
Mac compatibility	No
Ethernet LAN (RJ-45) ports	2
Display resolution	128 x 64 pixels
Display number of colors	Monochrome
Headphone connectivity	2.5 mm

Weight and Dimensions

Depth	212 mm
Width	214 mm
Height	44 mm
Weight	900 g
