Configuring Security, Quality, and Network Features
Configuring SSL VPN on the Cisco SPA 525G/525G2
Cisco Small Business SPA 300 Series, SPA 500 Series, and WIP310 IP Phone Administration Guide 138
5
STEP 4 Scroll to VPN and press the right arrow key.
STEP 5 Under VPN server, enter the IP address of the VPN server.
STEP 6 Enter the username to log in to the VPN server.
STEP 7 Enter the password for the user.
STEP 8 (Optional) Enter the tunnel group, if required by the VPN server.
STEP 9 (Optional) To connect to the VPN when the phone is powered on, ensure that
Connect on Bootup is enabled.
STEP 10 To connect to the VPN, ensure that Connect is enabled.
STEP 11 Press Save. After the VPN connection is established, a VPN icon appears in the
upper right of the phone display screen.
To view the VPN status, either:
• Use the configuration utility:
- Click Admin Login and advanced. (Not applicable to the SPA 525G/
525G2 in SPCP mode.) Click the Info tab.
• Use the phone menu:
- Press the Setup button. Scroll to Status and press Select. Scroll to VPN
Status and press Select.

Cisco SPA 508G Specifications

General

Speakerphone	Yes
Dialer location	Base
Mac compatibility	No
Ethernet LAN (RJ-45) ports	2
Display resolution	128 x 64 pixels
Display number of colors	Monochrome
Headphone connectivity	2.5 mm

Weight and Dimensions

Depth	212 mm
Width	214 mm
Height	44 mm
Weight	900 g
