Cisco SPA 508G Administration Guide

Customizing Cisco SPA and Wireless IP Phones
Configuring Ring Tones
Cisco Small Business SPA 300 Series, SPA 500 Series, and WIP310 IP Phone Administration Guide 62
3
STEP 6 Enter the target. You can have up to two customized ring tones uploaded to the
phone.
STEP 7 (Optional) Click Preview to preview the ring tone. Click Options to change the start
or end positions, or to squeeze or stretch the audio.
STEP 8 Click Upload to Phone to upload the ring tone to the phone. Click OK when the
success status message appears.
STEP 9 Close the open Ring Tone Utility windows.
To create a ring tone and save it to a file:
STEP 1 Open the Ring Tone Utility.
STEP 2 Enter the IP address of the user’s phone or press Skip to create the ring tone and
save it as a file.
STEP 3 Click Browse and navigate to the directory on your computer where the source
wav file is stored. Select the wav file and click Open.
STEP 4 Click Load.
STEP 5 Enter a name for the ring tone. This name will appear in the phone display. You
choose the file name later.
STEP 6 (Optional) Click Preview to preview the ring tone. Click Options to change the start
or end positions, or to squeeze or stretch the audio.
STEP 7 Click Save As to save the file to your computer. Enter the file name and press Save.
STEP 8 Close the open Ring Tone Utility windows.
To delete a ring tone from a phone:
STEP 1 Open the Ring Tone Utility.
STEP 2 Enter the IP address of the phone.
STEP 3 Click the Delete button next to the ring tone you want to delete.

Cisco SPA 508G Specifications

General

Speakerphone	Yes
Dialer location	Base
Mac compatibility	No
Ethernet LAN (RJ-45) ports	2
Display resolution	128 x 64 pixels
Display number of colors	Monochrome
Headphone connectivity	2.5 mm

Weight and Dimensions

Depth	212 mm
Width	214 mm
Height	44 mm
Weight	900 g
