Customizing Cisco SPA and Wireless IP Phones
Configuring Lightweight Directory Access Protocol (LDAP) for the Cisco SPA 300 Series and Cisco SPA
500 Series IP Phones
Cisco Small Business SPA 300 Series, SPA 500 Series, and WIP310 IP Phone Administration Guide 76
3
LDAP Client DN Enter the distinguished name domain components
[dc] ; for example:
dc=cv2bu,dc=com
If using the default Active Directory schema
(Name(cn)->Users->Domain), an example of the
client DN follows:
cn="David Lee",dc=users,dc=cv2bu,dc=com
LDAP Username Enter the username for a credentialed user on the
LDAP server.
LDAP Password Enter the password for the LDAP username.
LDAP Search Base Specify a starting point in the directory tree from
which to search.
Separate domain components [dc] with a comma.
For example:
dc=cv2bu,dc=com
LDAP Last Name Filter This defines the search for surnames [sn], known as
last name in some parts of the world. For example,
sn:(sn=*$VALUE*). This search allows the provided
text to appear anywhere in a name, beginning,
middle, or end.
You must enter a value in both the last name and first
name fields so that the LDAP corporate directory
option displays on the phone. If both fields are
empty, the directory does not display.
LDAP First Name Filter This defines the search for the common name [cn].
For example, cn:(cn=*$VALUE*). This search allows
the provided text to appear anywhere in a name,
beginning, middle, or end.
You must enter a value in both the last name and first
name fields so that the LDAP corporate directory
option displays on the phone. If both fields are
empty, the directory does not display.
LDAP Search Item 3 Additional customized search item. Can be blank if
not needed.
LDAP Item 3 Filter Customized filter for the searched item. Can be
blank if not needed.
Parameter Description
