Configuring VPN
VPN Passthrough
127
Ser
vic
es Ready Platf
orm S
RP
500 Series Administration Guide
7
L2TP
P
as
sthr
ough
La
yer 2 T
unneling Prot
oc
ol is the method use
d to enable
P
oint-t
o-Point ses
sions via the Int
ernet on the
La
yer 2
level. L2TP P
as
s-
Through is enabled by default
. T
o
di
sable
L2
TP P
asst
hr
oug
h, se
lect
Disa
bled.
Fie
l
d
D
e
s
c
r
ip
ti
on
126
128
Table of Contents
Default Chapter
2
WPS Method
2
Table of Contents
3
WPS Method
3
Chapter 1: Introduction to the Services Ready Platform
8
Feature Overview
8
Product Overview
8
SRP 521W Front Panel
9
SRP 526W / SRP 527W Front Panel
9
SRP 521W Back Panel
10
SRP 526W / SRP 527W Back Panel
11
Side Panels
12
Top View
13
Default Settings
14
Chapter 2: Getting Started with the Configuration Utility
15
Logging in to the Configuration Utility
15
Using the Configuration Utility
16
Main Window Areas
16
Configuration Utility Icons
17
Chapter 3: The Quick Setup Menu
19
Basic Configuration Setup
19
WAN Setup (Ethernet)
19
WAN Setup (ADSL)
25
LAN Setup
27
Wireless Setup
30
Remote Provisioning
36
Advanced Configuration
38
Voice
38
Mobile Network Setup
38
Firewall
39
Nat
39
Chapter 4: Setting up the Interfaces of the Services Ready Platform
40
Setting up the WAN Interface
40
Internet Setup
40
VC Setting
43
IPOA Settings / Static IP Setting
44
Pppoe Settings
44
Pppoa Settings
46
Mobile Network
46
Failover and Recovery (SRP 521W)
50
Failover and Recovery (SRP 526W, SRP 527W)
53
Setting up the LAN Interface
56
DHCP Server
56
VLAN Setting
60
Port Setting
62
Setting up the Wireless LAN
63
Basic Wireless Settings
63
Wireless Protected Setup
66
WPS Method 1
66
WPS Method 3
67
Wireless MAC Filter
69
Advanced Wireless Settings
71
WMM Setting
75
Using the Management Interface
76
Chapter 5: Configuring the Network
78
Static Routing
78
Rip
80
Intervlan Routing
81
Nat
81
Setting
81
Port Forwarding
82
Port Range Triggering
84
Qos
86
Bandwidth Control
86
Qos Policy
87
Qos Settings
88
Cos to Queue
89
DSCP to Queue
90
Firewall
91
Firewall Filter
91
Internet Access Control
94
Pppoe Relay
96
Ddns
98
Dmz
102
Igmp
103
Upnp
105
CDP Setting
106
Chapter 6: Voice Settings
108
Info
108
System
109
Sip
110
Provisioning
111
Regional
117
Chapter 7: Configuring VPN
118
IKE Policy
118
Ipsec Policy
120
GRE Tunnel
123
VPN Passthrough
125
Chapter 8: Administration Settings
128
Web Access Management
128
Settings
128
Remote Management
130
Tr069
130
Snmp
132
Local TFTP
133
Time Setup
135
Setup Wizard
137
User List
137
User Privilege Control
138
User Privilege Control Log
138
Factory Defaults
140
Firmware Upgrade
142
Backup & Restore
142
Backup Configuration
142
Restore Configuration
143
Reboot
144
Status
145
Switch Setting
146
Chapter 9: Using Services Ready Platform Diagnostics
148
Ping Test
148
Traceroute Test
149
Detect Active LAN Clients
150
Chapter 10: Viewing the Services Ready Platform Status
152
Router Settings
152
Firewall Status
154
Interface Information
156
Wireless Network
158
Wireless Client Information
159
Mobile Network
160
DHCP Server Information
163
Qos Status
164
Routing Table
165
ARP Table
166
RIP Status
167
IGMP Status
168
VPN Status
169
CDP Neighbor Information
169
Appendix A: Specifications
172
Appendix B: Where to Go from here
174
Product Resources
174
