Cisco SRP521W User Manual

Introduction to the Services Ready Platform
Product Overview
Services Ready Platform SRP 500 Series Administration Guide 9
1
SRP 521W Front Panel
SRP 526W / SRP 527W Front Panel
LED Description
Power/Sys Solid green indicates that the SRP is powered on.
Green flash indicates that the SRP is booting.
LAN Ports 1 to 4 Solid green indicates link. Green flash indicates link
traffic.
WAN
(SRP 521W only) Solid green indicates link. Green flash indicates link
traffic.
DSL CD
(SRP 526W/527W
only)
Solid green indicates carrier detection.
DSL Data
(SRP 526W/527W
only)
Green flash indicates DSL activity.
WLAN Solid green indicates the radio is operational. Green
flash indicates wireless traffic.
276377
LANPOWER/SYS PHONE USB WPSWLANWLAN
Cisco Small Business Pro
SRP 521W
12 2143
195210
LANPOWER/SYS PHONE CD Data
DSL
USB WPSWLAN
Cisco Small Business Pro
SRP 526W
12 2143

Cisco SRP521W Specifications

General

Brand	Cisco
Model	SRP521W
Category	Wireless Router
Language	English
