The Quick Setup Menu
Basic Configuration Setup
27 Services Ready Platform SRP 500 Series Administration Guide
3
LAN Setup
The LAN Setup page lets you quickly setup the LAN interface.
Qos Type Select the Quality of Service (QoS) method your ISP
uses on your line: Unspecified Bit Rate (UBR), Constant
Bit Rate (CBR), Real-Time Variable Bit Rate (RTVBR), or
Non-Real-Time Variable Bit Rate(NRTVBR). CBR
provides the best guarantee of low latency; UBR
provides none.
Pcr Rate—When QoS is set to CBR, VBR_RT,or
VBR_NRT, the Peak Cell Rate (PCR) in cells per second
must be entered here.
Scr Rate—When QoS is set to VBR_NRT or VBR_RT, the
Sustained Cell Rate (SCR) in cells per second must be
entered here.
MBS—When QoS is set to VBR_NRT or VBR_RT, the
MBS in cells per second must be entered here.
CDVT—When QoS is set to CBR, VBR_NRT or VBR_RT,
the CDVT in cells per second must be entered here.
VPI/VCI Auto Detect You can enable or disable automatic detection of the VPI
and VCI values (see next) that identify your line to the
ATM net w ork .
Virtual Circuit The Virtual Path Identifier (VPI) and Virtual Channel
Identifier (VCI) are values used to identify your line to
your ISP's ATM network.
Static IP Setting Select this option if your ISP provides you with a static
IP address. Enter the following required information as
provided by your ISP: Internet IP Address, Subnet Mask,
and Default Gateway IP address. Optionally, you can
enter the IP addresses of up to three Domain Name
System (DNS) servers, or leave the fields blank to allow
a DNS server to be chosen dynamically.
Field Description
