Cisco TelePresence SX20 Quick Set Administrator Guide
Open TCP Ports
The web server within the codec prohibit or restrict the use of
nonsecure or unnecessary ports, protocols, modules, and/or
services. Some ports are open or closed by default.
TCP 22: SSH
You can close the port by setting SSH mode to Off.
NetworkServices SSH Mode: Off / On
TCP 80: HTTP
You can close the port by setting HTTP mode to Off or HTTPS.
NetworkServices HTTP Mode: HTTP+HTTPS / HTTPS / Off
TCP 443: HTTPS
You can close the port by setting HTTP mode to Off.
NetworkServices HTTP Mode: HTTP+HTTPS / HTTPS / Off
TCP 4043: Remote pairing software download
You can close the port by setting remote pairing for the Touch
panel to Off.
Peripherals Pairing CiscoTouchPanels RemotePairing: Off / On
TCP 4045: Remote pairing version information
You can close the port by setting remote pairing for the Touch
panel to Off.
Peripherals Pairing CiscoTouchPanels RemotePairing: Off / On
TCP 4053: Remote pairing port
You can close the port by setting remote pairing for the Touch
panel to Off.
Peripherals Pairing CiscoTouchPanels RemotePairing: Off / On
TCP 4051: Remote pairing session connection
The port is only available (and open) when a Touch panel is
remote paired with the video system. You can close the port by
setting remote pairing for the Touch panel to Off.
Peripherals Pairing CiscoTouchPanels RemotePairing: Off / On
TCP 4052: Remote pairing and forwarding
The port is only available (and open) when a Touch panel is
remote paired with the video system. You can close the port by
setting remote pairing for the Touch panel to Off.
Peripherals Pairing CiscoTouchPanels RemotePairing: Off / On
TCP 5060/5061: SIP listen ports
The SIP listen pors are open by default. The SIP listen ports are
disabled by the Cisco UCM (Unified Communication Manager).
You can close the ports by setting the SIP listen ports to Off.
SIP ListenPort: Off / On
The system settings are configured from
the Setup > Configuration page on the
web interface. Open a web browser and
enter the IP address of the video system
then sign in.
