1-11
Catalyst 2950 Desktop Switch Hardware Installation Guide
78-11157-02
Chapter 1 Overview
Front-Panel Description
Figure 1-10 LEDs on Catalyst 2950G-12-EI, 2950G-24-EI, and 2950G-24-EI-DC Switches
SYST RPS
DUPLX
MODE
SPEED
UTIL
S TAT
1X
2X
11X
12X
1
2
3
4
5
6
7
8
9
10
11
12
65395
Mode button
Port mode
LEDs
System
LED
Port status
LEDs
RPS
LED
