Chapter 2 Installation
Where to Go Next
Figure 2-33 Connecting to a Console Port Only on Catalyst 2950G-48-EI Switches
Step 4 Attach the DB-9 adapter to a PC, or attach an appropriate adapter to the terminal.
Step 5 Insert the other cable end in the attached adapter.
Step 6 Boot the terminal-emulation software.
Where to Go Next
For information about starting up the switch, refer to the Release Notes for the
Catalyst 2950 Switch.
For information about configuring the switch, refer to the Catalyst 2950 Desktop
Switch Software Configuration Guide.
